2020 5 & 25mm Offset Drilling Jig — Blind Joints in 20 Series Extrusion (Video)
Share
What this jig does
It drills two M6 holes with their centres 5mm and 25mm from the edge of a 20 series extrusion, for a blind joint that needs no external bracket. Two built-in magnets let it stick to any steel surface for storage. 3D-printed by The Aluminum Carpenter for all 20 series extrusion.
Where you see it working
The video above is the floating desk and drawer cabinet build, cued to the drawer cabinet section where the 2020 offset and freehand jigs do the drilling.
