Robot Arms Workbench (Download)

This is a Digital Download.

This is not simply a workbench. It is a precision-engineered platform — purpose-built to house and support multiple robotic arms in a real-world industrial environment. Every extrusion, every drilled hole, and every internal channel was meticulously planned to accommodate complex wiring, heavy-duty components, and the relentless demands of automated systems.

From the ground up, this structure was designed with intention. We combined 40 and 50 series aluminum extrusions to create an extremely rigid, modular frame capable of handling the dynamic forces of active robotics. But the true innovation lies beneath the surface. Within the extrusion slots, a carefully orchestrated network of electrical wiring powers eight individual LED strips, all controlled by just five switches through a custom-designed, 3D-printed switchboard. Mains power exits discreetly through precisely located drill points, routing cleanly to the PSU — not a single exposed cable in sight.

Every custom component — from PSU mounts to cable covers — was 3D printed in ABS, delivering the strength and precision required for long-term reliability.

The result is more than a workbench. It is a ready-to-deploy platform for automation, built to evolve with the technology it supports.

Basic Dimensions : 2330*1140*2100mm (Length*Width*Height)

You will find 1,140 individual parts meticulously drawn, labeled, and organized within the 3D model. By following this 3d modeled design along with the list(s) provided, you will be able to build one for yourself. Upon purchase, you will be directed to a download link to obtain your digital files.

In this download, you will find all the necessary files to build one for yourself, including the Material List, Product Links, 3D Model (PDFs, DXFs, STEP & Shapr3D), STLs, 3MFs and Drilling Diagrams. You may stretch, alter, and amend the design to fit your desired dimensions. With this purchase, you will grasp the concept of building with 8020 aluminum extrusion.

You will need a specific Drilling & Alignment Jigs Set to complement your accurate and precise workflow in completing your assembly.

1) 5050 to 4080 Twin Freehand Drilling Jig M8

2) 5050 to 4080 20 & 60mm Offset Drilling Jig M8

3) 50100 to 4080 Freehand Drilling Jig M8

4) 4080 Center Freehand Drilling Jig M12

5) 4040 28mm Offset Drilling Jig M8

6) 4040 18 & 38mm Offset Drilling Jig M8

7) 4080 28mm Offset Drilling Jig M8

8) 4080 18 & 38mm Offset Drilling Jig M8

9) 4040 Freehand Drilling Jig M4

10) 4080 Quad Freehand Drilling Jig M8

11) 4080 Bi Freehand Drilling Jig M8

12) 4040 20mm Offset Drilling Jig M8

13) 4040 Perpendicular Alignment Jig 90mm

14) 5050 to 4080 Alignment Jig (Set of 4)

15) 40 to 50 Alignment Jig (Set of 4)
